Color Switch Boxes Plastic, Screw Type, Knock-out Base
| SIZE |
MODELS |
Dimensions (unit : mm) |
| W1 x L1 x H1(unit: mm) |
W x L x H(unit: inch) |
Grey Cover
Black Base |
Yellow Cover
Black Base |
Inner
Height |
Panel
Hole |
No of Holes |
A |
B |
C |
| 80×110×70 |
3.15×4.33×2.76 |
BC-AGB-081107-2201 |
BC-AYB-081107-2201 |
57 |
22.3 |
1 |
40 |
55 |
– |
| 80×110×85 |
3.15×4.33×3.35 |
BC-AGB-081108-2201 |
BC-AYB-081108-2201 |
72 |
| 80×130×70 |
3.15×5.12×2.76 |
BC-AGB-081307-2202 |
BC-AYB-081307-2202 |
57 |
2 |
40 |
50 |
| 80×130×85 |
3.15×5.12×3.35 |
BC-AGB-081308-2202 |
BC-AYB-081308-2202 |
72 |
| 80×180×70 |
3.15×7.09×2.76 |
BC-AGB-081807-2203 |
BC-AYB-081807-2203 |
57 |
3 |
| 80×180×85 |
3.15×7.09×3.35 |
BC-AGB-081808-2203 |
BC-AYB-081808-2203 |
72 |
| 80×250×70 |
3.15×9.84×2.76 |
BC-AGB-082507-2204 |
BC-AYB-082507-2204 |
57 |
4 |
50 |
| 80×250×85 |
3.15×9.84×3.35 |
BC-AGB-082508-2204 |
BC-AYB-082508-2204 |
72 |
| 80×110×70 |
3.15×4.33×2.76 |
BC-AGB-081107-2501 |
BC-AYB-081107-2501 |
57 |
25.2 |
1 |
40 |
55 |
– |
| 80×110×85 |
3.15×4.33×3.35 |
BC-AGB-081108-2501 |
BC-AYB-081108-2501 |
72 |
| 80×130×70 |
3.15×5.12×2.76 |
BC-AGB-081307-2502 |
BC-AYB-081307-2502 |
57 |
2 |
40 |
50 |
| 80×130×85 |
3.15×5.12×3.35 |
BC-AGB-081308-2502 |
BC-AYB-081308-2502 |
72 |
| 80×180×70 |
3.15×7.09×2.76 |
BC-AGB-081807-2503 |
BC-AYB-081807-2503 |
57 |
3 |
| 80×180×85 |
3.15×7.09×3.35 |
BC-AGB-081808-2503 |
BC-AYB-081808-2503 |
72 |
| 80×250×70 |
3.15×9.84×2.76 |
BC-AGB-082507-2504 |
BC-AYB-082507-2504 |
57 |
4 |
50 |
| 80×250×85 |
3.15×9.84×3.35 |
BC-AGB-082508-2504 |
BC-AYB-082508-2504 |
72 |
| 80×110×70 |
3.15×4.33×2.76 |
BC-AGB-081107-3001 |
BC-AYB-081107-3001 |
57 |
30 |
1 |
40 |
55 |
– |
| 80×110×85 |
3.15×4.33×3.35 |
BC-AGB-081108-3001 |
BC-AYB-081108-3001 |
72 |
| 80×130×70 |
3.15×5.12×2.76 |
BC-AGB-081307-3002 |
BC-AYB-081307-3002 |
57 |
2 |
40 |
50 |
| 80×130×85 |
3.15×5.12×3.35 |
BC-AGB-081308-3002 |
BC-AYB-081308-3002 |
72 |
| 80×180×70 |
3.15×7.09×2.76 |
BC-AGB-081807-3003 |
BC-AYB-081807-3003 |
57 |
3 |
| 80×180×85 |
3.15×7.09×3.35 |
BC-AGB-081808-3003 |
BC-AYB-081808-3003 |
72 |
| 80×250×70 |
3.15×9.84×2.76 |
BC-AGB-082507-3004 |
BC-AYB-082507-3004 |
57 |
4 |
55 |
| 80×250×85 |
3.15×9.84×3.35 |
BC-AGB-082508-3004 |
BC-AYB-082508-3004 |
72 |
|
| Protection Level |
Water proof: IP66/67, Impact Test: IK07/08 |
| Technical |
Smooth sidewalls |
| Standard or Quick turn screws |
| Integrated cover retainer |
| Color |
Gray or yellow cover with black base |
| Temperature range |
ABS: -40°C to 70°C (-40°F to 158°F) |
| Flammability Rating |
ABS: UL94-HB |
|
