MC/MT Series Contractors & Overload Relay

Key Features

  • Advanced technology & Expert solution
  • Offering economical solution with compact size & easy connection
  • Ensure reliability in the system: Type II Coordination
  • Perfect system with peripheral devices
  • Environment friendly product: complies with International environment standard RoHS
  • 25Models in 9 Frames
① Product (6A~2650A)
6A MC6a
MC2650A MC-2650a
9B MC-9b
22B MC-22b
② Main contactor
30 3NO 0NC
40 4NO 0NC
22 2NO 2NC
③ Auxiliary contact
00 None
11 Normal 1NO Normal 1NC
22 Normal 2NO Normal 2NC
11L Low Current 1NO Low current 1NC
22L Low Current 2NO Low current 2NC
11H Hoist 1NO Normal 1NC
22H Hoist 2NO Normal 2NC
④ Coil voltage
See Coil code Table
Terminals
S Screw
L Lug
B hex Bolt

① Rated current
12 12AF
32 32AF
63 63AF
95 95AF
150 150AF
225 225AF
400 400AF
800 800AF
② Relay version
3H Non-differential (3-heater)
3K Differential
3D Class 20
③ Relay setting current
0.1 0.1A
800 800A
