| 3-Phase 200V Class (0.4~7.5kW) |
|
0004 |
0008 |
0015 |
0022 |
0040 |
0055 |
0075 |
| Motor
Rating |
Heavy Duty |
HP |
0.5 |
1.0 |
2.0 |
3.0 |
5.4 |
7.5 |
10 |
| kW |
0.4 |
0.75 |
1.5 |
2.2 |
4.0 |
5.5 |
7.5 |
| Normal Duty (ND) |
HP |
1.0 |
2.0 |
3.0 |
5.4 |
7.5 |
10 |
15 |
| KW |
0.75 |
1.5 |
2.2 |
4.0 |
5.5 |
7.5 |
11 |
| Output
Rating |
Capacity [kVA] |
Heavy Duty (HD) |
1.0 |
1.9 |
3.0 |
4.2 |
6.5 |
9.1 |
12.2 |
| Normal Duty (ND) |
1.2 |
2.3 |
3.8 |
4.6 |
6.9 |
11.4 |
15.2 |
| Rated Current
(3-Phase Input) [A] |
Heavy Duty (HD) |
2.5 |
5.0 |
8.0 |
11.0 |
17.0 |
24.0 |
32.0 |
| Normal Duty (ND) |
3.1 |
6.0 |
9.6 |
12.0 |
18.0 |
30.0 |
40.0 |
| Rated Current
(1-Phase Input) [A] |
Heavy Duty (HD) |
1.5 |
2.8 |
4.6 |
6.1 |
9.3 |
12.8 |
17.4 |
| Normal Duty (ND) |
2.0 |
3.6 |
5.9 |
6.7 |
9.8 |
16.3 |
22.0 |
| Frequency [Hz] |
0~400Hz (IM sensorless: 0~120Hz) |
| Voltage [V] |
3-Phase 200~240V |
| Input
Rating |
Voltage [V] |
3-Phase 200~240VAC (-15%~+10%) |
| Frequency [Hz] |
50~60Hz (±5%) |
| Rated Current [A] |
Heavy Duty (HD) |
2.2 |
4.9 |
8.4 |
11.8 |
18.5 |
25.8 |
34.9 |
| Normal Duty (ND) |
3.0 |
6.3 |
10.8 |
13.1 |
19.4 |
32.7 |
44.2 |
| Weight [kg] |
1.04 |
1.06 |
1.36 |
1.4 |
1.89 |
3.08 |
3.21 |
| 3-Phase 400V Class (0.4~7.5kW) |
|
0004 |
0008 |
0015 |
0022 |
0040 |
0055 |
0075 |
| Motor
Rating |
Heavy Duty |
HP |
0.5 |
1.0 |
2.0 |
3.0 |
5.4 |
7.5 |
10 |
| kW |
0.4 |
0.75 |
1.5 |
2.2 |
4.0 |
5.5 |
7.5 |
| Normal Duty (ND) |
HP |
1.0 |
2.0 |
3.0 |
5.4 |
7.5 |
10 |
15 |
| KW |
0.75 |
1.5 |
2.2 |
4.0 |
5.5 |
7.5 |
11 |
| Output
Rating |
Capacity [kVA] |
Heavy Duty (HD) |
1.0 |
1.9 |
3.0 |
4.2 |
6.5 |
9.1 |
12.2 |
| Normal Duty (ND) |
1.5 |
2.4 |
3.9 |
5.3 |
7.6 |
12.2 |
17.5 |
| Rated Current
(3-Phase Input) [A] |
Heavy Duty (HD) |
1.3 |
2.5 |
4.0 |
5.5 |
9.0 |
12.0 |
16.0 |
| Normal Duty (ND) |
2.0 |
3.1 |
5.1 |
6.9 |
10.0 |
16.0 |
23.0 |
| Rated Current
(1-Phase Input) [A] |
Heavy Duty (HD) |
0.7 |
1.4 |
2.1 |
2.8 |
4.9 |
6.4 |
8.7 |
| Normal Duty (ND) |
1.3 |
1.9 |
2.8 |
3.6 |
5.4 |
8.7 |
12.6 |
| Frequency [Hz] |
0~400Hz (IM sensorless: 0~120Hz) |
| Voltage [V] |
3-Phase 380~480V |
| Input
Rating |
Voltage [V] |
3-Phase 380~480VAC (-15%~+10%) |
| Frequency [Hz] |
50~60Hz (±5%) |
| Rated Current [A] |
Heavy Duty (HD) |
1.1 |
2.4 |
4.2 |
5.9 |
9.8 |
12.9 |
17.5 |
| Normal Duty (ND) |
2.0 |
3.3 |
5.5 |
7.5 |
10.8 |
17.5 |
25.4 |
| Weight [kg] |
1.02 (1.04) |
1.06 (1.08) |
1.4 (1.44) |
1.42 (1.46) |
1.92 (1.98) |
3.08 (3.24) |
3.12 (3.28) |
| Control |
| Control Method |
V/F, Slip Compensation, Sensorless Vector |
| Frequency Setting Resolution |
Digital command: 0.01Hz
Analog command: 0.06Hz(maximum frequency: 60 Hz) |
| Frequency Accuracy |
1% of the maximum output frequency |
| V/F Pattern |
Linear, squared, user V/F |
| Overload Capacity |
HD: 150% 1 minute, ND: 120% 1minute |
| Torque Boost |
Manual/Automatic torque boost |
| Operation |
| Operation Mode |
Select key pad, terminal strip, or communication operation |
| Frequency Setting |
Analog: -10~10[V], 0~10[V], 4~20[mA]
Digital: Keypad |
| Operation Function |
PID control, 3-wire operation, Frequency limit, Second function, Anti-forward and reverse direction
rotation, Commercial transition, Speed search, Power braking, Leakage reduction, Up-down operation,
DC braking, Frequency jump, Slip compensation, Automatic restart, Automatic tuning, Energy buffering,
Flux braking, Fire mode |
| Input |
Multi-Function Terminal
(5 Points) |
NPN (Sink) / PNP (Source) Selectable |
| Function: Forward run, Reverse run, Reset, External trip, Emergency stop, Jog operation, Multi-step frequencyhigh,
middle, low, Multi-step acceleration/ deceleration-high, middle, low, DC braking at stop, 2nd motor select,
Frequency up/down, 3-wire operation, Change into normal operation during PID operation, Change into main body
operation during option operation, Analog command frequency fixing, Acceleration/deceleration stop etc. Selectable |
| Analog Input |
V1: -10~10V, I2 4~20mA |
| Output |
Multi-function Relay Terminal |
Fault output and drive operation status output |
(N.O., N.C.) less than AC 250V 1A, less than DC 30V 1A |
| Analog Output |
0~12Vdc: Frequency, Output current, Output voltage, DC stage voltage etc. selectable |
| Protective Function |
| Trip |
Over current trip, external signal trip, ARM short
current fault trip, over heat trip, input imaging trip,
ground trip, motor over heat trip, I/O board link trip,
no motor trip, parameter writing trip, emergency
stop trip, command loss trip, external memory error,
CPU watchdog trip, motor light load trip |
Over voltage trip, temperature sensor trip, inverter
over heat, option trip, output image trip, inverter
overload trip, fan trip, pre-PID operation failure
external brake trip, low voltage trip during operation,
low voltage trip, analog input error, motor overload
trip, over torque trip, under torque trip |
| Alarm |
Command loss trip warning, overload warning, light load warning, inverter overload warning,
fan operation warning, braking resistance braking rate warning, rotor time constant tuning error, inverter pre-overheat warning, over torque warning, under torque warning |
| Momentary Power Loss |
HD below 15ms (ND below 8ms): Continuous operation (To be within rated input voltage, rated output) HD above 15ms (ND above 8ms): Automatic restart operation enable |
| Environment |
| Cooling Type |
Forced fan cooling structure |
| Protection Degree |
IP20/UL Open (Default), UL Enclosed type 1 (Option) |
| Ambient Temperature |
Ambient temperature under the condition of no ice or frost.
HD: -10~50℃(14~122°F) / ND: -10~40℃(14~104°F)
[However, recommended to use load below 80% when using at 50°C under light load] |
| Humidity |
Relative humidity below 95% RH (no dew formation) |
| Storage Temperature |
-20~65℃(-4~149°F) |
| Location |
No corrosive gas, flammable gas, oil mist and dust etc. indoors (Pollution degree 2 environment) |
| Altitude, Vibration |
Below 1,000m (From 1000 to 4000m, the rated input voltage and rated output current
of the drive must be derated by 1% for every 100m.), below 9.8m/sec2 (1G) |
| Pressure |
70~106kPa |
| Certificate/Compliance |
UL, CE |
|
① Rated Motor
