| Power supply |
12 ~ 24VDC, 110 ~ 220VAC (50/60Hz) |
| Allowable voltage
range |
10.8V ~ 26.4VDC, 100 ~ 240VAC |
| Current consumption
(±10%) |
12~24VDC : 0.28A
110~220VAC : 0.07A |
| Function |
Flashing |
| Dimension |
95 x 95 x 94 (mm) |
| Flashing rate |
12~18VDC : 80±5 times per min ute
110VAC : 77±5 times per minute
220VAC : 60±5 times per minute |
| Mounting method |
Body bottom mount base – Screw type (M6, 2EA) |
| Power cable insertion |
Internal bottom of main body
– Maximum cable diameter : Ø7mm
External locations
– Cable gland |
| Connection |
UL1007/AWG22) |
| Color |
Red, Yellow, Green, Blue, Clear |
| Material |
Body – PA6 Lens – PC |
| Insulation resistancee |
Over 100MΩ
(500VDC mega between terminals and case ) |
| Withstand voltagee |
500VAC 50/60Hz 1 min
(betwen terminls and case before ) |
| Vibration |
0.75mm at 10~55Hz (cycle: 1minute) |
| Temperature |
Ambient temperature : -20 ~ 50°C
Storage ambient temperature: -20 ~ 70°C |
| Ambient humidity |
45 ~ 85% RH |
| Protection structure |
IP65 |
| Weight |
App. 300g (AC type standard) |
