MQVL Series 95mm Cube LED Signal Lights, Steady/Flash



Key Features

  • Steady/flashing light with IP65 protection
  • Cubic shape stackable with other MQV modules
  • Designed to couple with MQV S/H speaker series
  • Clear bright lighting through prism-cut lens


① Power Supply
00 12~24VDC
FF 110~220VAC
② Lens Color
R Red
Y Yellow
G Green
B Blue
C Clear
③ Option
V 240 ±10 times/minute (Emergency signal)


Power supply 12 ~ 24VDC, 110 ~ 220VAC (50/60Hz)
Allowable voltage range 10.8V ~ 26.4VDC, 100 ~ 240VAC
Current consumption (±10%) 12~24VDC : 0.28A 110~220VAC : 0.07A
Function Steady, Flashing
Dimension 95 x 95 x 94 (mm)
Flashing rate Standard – 80±5 per minute Option (V) type – 240±10 times per minute
Mounting method Body bottom mount base – Screw type (M6, 2EA)
Power cable insertion Internal bottom of main body – Maximum cable diameter : Ø7mm External locations – Cable gland
Connection UL1007/AWG22)
Color Red, Yellow, Green, Blue, Clear
Material Body – PA6 Lens – PC
Insulation resistancee Over 100MΩ (500VDC mega between terminals and case )
Withstand voltagee 500VAC 50/60Hz 1 min (betwen terminls and case before )
Vibration 0.75mm at 10~55Hz (cycle: 1minute)
Temperature Ambient temperature : -20 ~ 50°C Storage ambient temperature: -20 ~ 70°C
Ambient humidity 45 ~ 85% RH
Protection structure IP65
Weight App. 300g (AC type standard)
