MS86L Series Ø86mm LED Signal Lights, Steady/Flash, Various mountable

Key Features

  • Wide light distribution with prism-cut lens
  • Selectable Steady/Flashing modes by jumper
① Light Style
F LED Steady & Flashing
B LED Steady & Flashing with buzzer
② Power supply
02 24 VAC/DC
FF 90 – 240 VAC
③ Lens colors
R Red
Y Yellow
G Green
B Blue
C Clear
Model MS86L
Style LED Steady/Flashing
Power Supply 24VAC/DC 90~240VAC
Current Consumption Red 330mA 30mA ~ 50mA
Yellow 330mA
Green 460mA
Blue 460mA
Clear 460mA
Buzzer 30mA
Certificate/Compliance RoHS, UL
Flash rate 80 time/min. ±3%
Rotation rate N/A
Buzzer sound level Max. 80dB
Vibration 0.75mm at 10 ~ 55Hz
Insulation resistance 100MΩ minimum (500VDC mega)
Ambient Temperature -20 ~ 40 ̊C
Storage Temperature -20 ~ 70 ̊C
Ambient humidity 45 ~ 85% RH
Degree of Protection IP65
Recommended wire size PUR Ø5/PVCØ1.25 2P 0.3SQ, 300mm
Weight 150g
Light catalog Mounting options Mounting options for MS86
  • MS86 Series
