MSGT Series D140mm Square Tower Warning Signal Light

Key Features

  • Large 140mm lens, flashing & rotating LED light
  • Outstanding visibility with dual reflection system
  • 5 signal sounds up to 100dB
  • Built-in LED mode change switch
  • Stud or Wall mounting with optional bracket
① Number of stack
1 1 Light
2 2 Lights
3 3 Lights
4 4 Lights
② Power supply
01 12VAC/DC
02 24VAC/DC
10 110VAC
20 220VAC
③ Lens colors
R Red
Y Yellow
G Green
B Blue

Lighting Type Steady, Flashing, Rotation
Power Supply Incandescent
Power Supply 12VDC ±5%, 24VDC ±5% 110VAC ±10%, 220VAC ±10% (AC: 50/60Hz)
Maximum stacked quantity Fixed frame, 1~3 stack versions available (4 stack : option)
Flashing rate Continuous flashing (emergency signal) 240 ±10 times per minute
Rotating rate 250 ±10rpm (Clockwise Rotation)
Sound volume Speaker 15W / App. 100 ±5dB at 1 meter
Ambient humidity 45 ~ 85% RH
Ambient temperature -15 ~ 40°C
Storage ambient temperature -20 ~ 70°C
Vibration 0.75mm at 10 ~ 55Hz
Withstand voltage 500VAC 50/60 Hz for 1 minute
Insulation resistance More than 100MΩ (500VDC)
Protection structuree IP23 (Upright)
Weigh App. [1S: 2.7Kg] [2S: 3.3Kg] [3S: 4.0Kg]
LED PCB Replacement
M8-12V-R Red
M8-12V-Y Yellow
M8-12V-G Green
M8-12V-B Blue
M8-12V-W White
*Input Power: DC 12V *Current: 100mA±10%
