| Model |
MW86T |
| Style |
LED Steady/Flashing/Rotating |
| Power Supply |
12 ~ 24 VDC |
90 ~ 240 VAC(50~60Hz) |
| Current
Consumption |
LIght |
Max 0.32A ±10% |
Max. 0.10A ±10% |
| Sound |
Max 0.20A ±10% |
Max. 0.06A ±10% |
| Flash rate |
80±5 times/min(F1), 240±10 times/min(F3) |
| Rotation rate |
60 ~ 300 ±10 RPM |
| Buzzer sound level |
Standard type |
55~85±5dB |
| Horn type |
55~90±5dB |
| Material |
Body: ABS, Lens: PC |
| Insulation resistance |
100MΩ minimum (500VDC mega) |
| Ambient Temperature |
-20 ~ 40 ̊C |
| Storage Temperature |
-20 ~ 70 ̊C |
| Ambient humidity |
45 ~ 85% RH |
| Degree of Protection |
Standard type: IP43, Horn type: IP54 |
| Recommended wire size |
UL1007/22AWG |
| Weight |
Standard type |
approx. 279g |
| Horn type |
approx. 306g |
| Certificate/Compliance |
RoHS |
|
