MWET Series 90mm Wall mounting Semicircular Multi-channel LED Signal Light



Key Features

  • 3 Colors Signal Light
  • Split lens can show different colors
  • Large LED Light-emitting Lens (93mm)
  • Optional built-in Alarm
  • IP65 (With Alarm: IP52)


① Housing Color (Optional)
no mark Cream
C Nickel-plated
② Light Style
F Steady/Flashing
B Steady/Flashing/Alarm
③ LED Signals
3 3 Colors
④ Power Supply
00 12~24VDC
FF 110~220VAC
⑤ LED Colors
RGB Red, Green, Blue
RYG Red, Yellow, Green
⑥ Lens Color (Optional)
No Mark Clear Lens
M Milky Lens


Power supply 12~24 DC 110~220 AC
Current Consumption Max 0.22A ±10% Max 0.08A ±10%
Flash Rate 12VDC 80±5 times per minute
24VDC 85±5 times per minute
110~220VAC 85±5 times per minute
Alarm Sound Level 75±5dB (at 1M, Sound Level is maximum)
Wiring Method Lead wire connection
Vibration Resistance 0.75mm at 10~55Hz
Dielectric strength 1000VAC 50/60Hz for 1min
Insulation Resistance I100 MΩ minimum (500VDC mega)
Ambient Temperature -20~40°C
Storage Temperature -20~70°C
Ambient Humidity 45~85% RH
Degree of Protection IP65 (IP52-Buzzer type)
Recommended Wire Size UL1007/22AWG
Weight AC type – About 300g, DC type – About 293g
Approvals RoHs, UL,CE
