PTE Series Ø56mm LED modular Stack Lights, Steady/Flash/Audible Alarm

Key Features

  • LED modular components
  • Optional 85 or 100dB buzzer (fixed or adjustable volume)
  • Power: 24VAC/DC or 90~240VAC
  • Lead wire or terminal connection
  • Pole mounting or direct mounting
  • IP65 rated
① Top head style
PTE Standard
PTD Dome head
② Body unit – Mounting/Connection
A Pole mounting/Lead wires
SC Direct mounting/Lead wires
T Pole mounting/Terminal connection
TC Direct mounting/Terminal connection
③ Light style
Steady Light
F Steady & Flashing light
④ Number of stack
1 1 Light
2 2 Lights
3 3 Lights
4 4 Lights
5 5 Lights
⑤ Power supply
02 24VAC/DC
FF 90~240VAC
⑥ Lens colors (top to buttom)
R Red
Y Yellow
G Green
B Blue
C Clear
1. Body units
Operation/Function Steady/Flashing
Power supply 24VAC/DC(±10%), 90~240VAC 50/60Hz(±10%)
Buzzer sound level Fixed: 85dB Adjustable: 1-~85dB, 10~100dB
Lens color Red, Yellow, Green, Blue and Clear
Maximum tier Standard type – 5 stacks, Buzzer type – 4 stacks
Flash rate 80 times/min ±10%, Option V type – 240 times/min ±10%
Vibration 0.75mm @10~55Hz: xyz/60min
Ambient temperature -15 ~ 40 ̊C
Storage temperature -25 ~ 70 ̊C
Ambient humidity 45 ~ 85% RH
Degree of protection IP65, IP40 with buzzer
Certificate/Compliance UL, RoHS, CE
Recommended wire size 1007 UL / 22AWG
2. LED Modules ±10%
LED Color 24VAC 90~240VAC
R 33mA 17mA
Y 27mA 17mA
G 42mA 22mA
B 42mA 22mA
C 42mA 22mA
Weight Approx. 43g
3. Buzzer kits
Model MPZ-56F MPZ-56G MPZ-56H
Style Fixed sound Adjustable sound Adjustable sound
Sound level 80±5dB at 1M 10 ~ 80±5dB at 1M 10 ~ 100±5dB at 1M
Current consumption(±10%) 30mA / 0.72W 30mA / 0.72W 150mA / 3.6W
Weight Approx. 33g Approx. 33g Approx. 33g


Pole with base mounting
Part Part number Description
1 MAP-0060 Ø20mm, 2.36 inch long pole
MAP-0240 Ø20mm, 9.45 inch long pole
MAP-0750 Ø20mm, 29.53 inch long pole
MAP-1000 Ø20mm, 39.37 inch long pole
2 MAM-B070C Ø70mm plastic base
MAM-B070D Ø70mm plastic base with waterproof rubber gasket
MAM-B070R Ø70mm plastic base with 180 degree rotating pole holder
MAM-B090 Ø90mm plastic base
3 MAM-DS32 Aluminum base
L-angle mounting with bracket
4 MAP-M043 Ø20mm, 1.69 inch long threaded pole with 2 nuts
MAP-M240 Ø20mm, 9.45 inch long threaded pole with 2 nuts
MAP-M750 Ø20mm, 29.53 inch long threaded pole with 2 nuts
5 MAM-DS25 L – angle bracket

Wall mounting with bracket
1 MAP-0060 Ø20mm, 2.36 inch long pole
MAP-0240 Ø20mm, 9.45 inch long pole
MAP-0750 Ø20mm, 29.53 inch long pole
MAP-1000 Ø20mm, 39.37 inch long pole
2 MAM-B070C Ø70mm plastic base
MAM-B070D Ø70mm plastic base with waterproof rubber gasket
MAM-B070F Ø70mm Base mounting only
6 MAM-DS40-BLK Plastic Wall Mounting Bracket, Black (Pole required)
MAM-DS40-BGE Plastic Wall Mounting Bracket, Beige (Pole required)
MAM-DS28 Plastic Wall Mounting Bracket, Black (Pole & Base required)
Body units
Body type Voltage Part number
Steady Flashing
Lead wire connection Pole mounting 90~240VAC PTE-A-FF-B PTE-AF-FF-B
24VAC/DC PTE-A-02-B PTE-AF-02-B
Direct mounting 90~240VAC PTE-SC-FF-B PTE-SCF-FF-B
24VAC/DC PTE-SC-02-B PTE-SCG-02-B
Terminal connection Pole mounting 90~240VAC PTE-T-FF-B PTE-TF-FF-B
24VAC/DC PTE-T-02-B PTE-TF-02-B
Direct mounting 90~240VAC PTE-TC-FF-B PTE-TCF-FF-B
24VAC/DC PTE-TC-02-B PTE-TCF-02-B
LED Modules
LED Color Part number
Standard module Dome head module
Red PTE-02-R PTD-02-R
Yello PTE-02-Y PTD-02-Y
Green PTE-02-G PTD-02-G
Blue PTE-02-B PTD-02-B
Clear* PTE-02-C PTD-02-C
*Clear module can’t be used with a buzzer.
Buzzer kits
Model MPZ-56F MPZ-56G MPZ-56H
Style Fixed sound Adjustable sound Adjustable sound
Sound level 80±5dB at 1M 10 ~ 80±5dB at 1M 10 ~ 100±5dB at 1M
Locking bolts
Number of LED Part number Size
1 stack B-PTE-1 M4, 65mm
2 stacks B-PTE-2 M4, 105mm
3 stacks B-PTE-3 M4, 145mm
4 stacks B-PTE-4 M4, 185mm
5 stacks B-PTE-5 M4, 225mm
